Universal input 100 to 240 VAC

Single, dual output options

Overload protection

100% Hi-Pot tested

100% cycling burnt-in

Output Specifications:

Line regulation 1%

Load regulation ±5%

Efficiency 80%

Hold up time 16ms

Transient response Main output 50-100% load 50% duty cycle

Protections: -- Over current -- Over voltage

-- Over power

-- Short circuit protections

Input Specifications:

Input voltage 90 to 264VAC

Input frequency 47 to 63 Hz

Input current 1.2A max.

Inrush current 50A max.

Electrical Specifications:

Dielectric strength test input/output: 4242VDC, input/output: 2121VDC

Leakage current <3.5mA

MTBF Min. 50,000 hours MIL-HDBK-217F

Environmental Specifications:

Operating temperature 0~40°C

Non-operating -20~80°C

Relative humidity non-condensing 10~85%

Convection cooling

Vibration 2.0G, 10-300Hz

Safety:

UL, cUL, CE

Please contact our sales representative for other safety marks.
