Features:
Universal input 100 to 120 VAC
Single, output
Overload protection
100% Hi-Pot tested
100% cycling burnt-in
Output Specifications:
Line regulation 1%
Load regulation ±5%
Efficiency 70%
Hold up time 16ms
Transient response Main output 50-100% load
Protections: -- Over current -- Over voltage
-- Over power
-- Short circuit protections
Input Specifications:
Input voltage 90 to 127VAC
Input frequency 47 to 63 Hz
Input current 0.4A max.
Inrush current 40A max. @250AVC
Electrical Specifications:
Dielectric strength test input/output: 4242VDC
Leakage current <0.25.5mA
MTBF Min. 50,000 hours MIL-HDBK-217F
Environmental Specifications:
Operating temperature 0~40°C
Non-operating -20~85°C
Relative humidity non-condensing 10~95%
Convection cooling
Vibration 2.0G, 10-300Hz
Safety:
USA, CSA |
|
|
