CompactPCI Power Backplanes with 1 or 2 or 3 47PIN connectors for CompactPCI

CompactPCI Power Backplanes with 1 or 2 or 3 47PIN connectors for CompactPCI

  • Country of Origin:Taiwan
  • Model:CPCIPWR-3U2S-A1; CPCIPWR-3U4S-A1; CPCIPWR-3U6S-A1
  • Minimum Order:Negotiable

Detail Specifications

◎ Comforms to PICMG2.11 CompactPCI Specification 47-pin power interface.
◎ Supports 3U & 6U cPCI power supplies
◎ Supports 47-pin power connectors
◎ Supports ATX power connectors
◎ Currant sharing on +5V, +3.3V, +12V and -12V

Specifications:
● P/N: TLIM-CPCIPWR-3U2S-A1
- One 47-pin connector supporting one 8HP power supply.
● P/N: TLIM-CPCIPWR-3U4S-A1
- Two 47-pin connectors supporting two 8HP power supply.
● P/N: TLIM-CPCIPWR-3U6S-A1
- Three 47-pin connectors supporting three 8HP power supply.
