CompactPCI 4U Chassis
- Country of Origin:Taiwan
- Model:P-484283-H-CP
- Minimum Order:Negotiable
Detail Specifications
4U CompactPCI Platforms, horzontal type, with 6U 8slots backplane, cPCI or ATX power supplies.
Specifications：
● Enclosure
- Material: aluminum with black painted for lighter weight and increased EMC/EMI protection.
- Dimensions: 4U (H) x 84T (W) x 285 mm (D)
- Front cage: 8-slot, 6U x 160mm
- Rear I/O: 8-slot, 6U x 80mm
● Backplane
- 6U 8 slots.
- PICMG2.0R3.0 or PICMG2.16 compliance.
● CompactPCI power supplies
- Power supply: 250W/ 300W cPCI type
- 47pin sockets for 1/2/3/4 cPCI power supplies
● ATX Power supplies
- 250W or 380W ATX power supplies
● Options:
- Device holders for HDD, CD ROM, slim CD ROM, 5.25" or 3.5" devices.
- Filler panels: 6U4HP, 6U8HP, 3U8HP, 3U16HP, etc.
