![LED模組 LED模組](https://www.cens.com/cens/supplier/18935/product/71825/BIG.jpg?xxx=1723658919519)
LED模組
Hot- 產品型號:
- CH-MY-3528X-4-D2
- 原產地:
- 中國
詳細規格及用途描述
Features:
1. Adopt Taiwan super flux 3528 LED.
2. Big beam angle, half angle is above 90 degree. Even color rendering and no facula.
3. Adopt web constant circuit, have super anti-static function and ensure the stability of the module.
4. Various colors for customers' choice, pure and genuine.
5. Colors:red, yellow, blue, green, white.
6. Adopt anti-static PVC material for the base to effectively prevent short circuit caused by the contact of the PCB soldering point and the metal cover.
7. Convenient and quick to install. With auto-lock connector and can be connected freely.
8. Convenient to connect: each module have plug and wires with low weight and compact size for easy intallation.
9. Low power consumption and energy saving (save 80% energy compared with neon light) with genuine color.
10. Long service life and good stability.
11. Low input voltage, safe and reliable.
Specifications:
1. Dimension: 29*29*5mm
2. LED Q'ty: 4pcs
3. Power: 0.24W
4. Voltage: 12V
5. Working temperature: -20℃~80℃
6. IP Rate:IP68
7. LED Size:3528 LED
8. LED Beam Angle: 120 degree
9. Colors: red, green, blue, yellow, white, warm white.
10. Service Life: 50,000hrs
Application:
1. solid lighting character
2. ultra-thin lamp box backlight
3. shop window lighting
4. interior decoration lighting
5. building curtain wall lighting
6. scenery designs
7. stage decoration
8. billboard and signboard
9. replace for neon light
