單層/夾層銀基片材

Features:

1. Both Cad-free and Cad bearing alloys can be used.

2. Silver alloys with Nickel or Manganese can solve the difficulty of brazing on carbides.

3. Silver alloy has the characteristics of low melting point and good fluid, which can apply to weld on the small Tungsten carbides - Silver containment of 35%,42%,45%,50%,56%.

4. Nickel and manganese containing alloys for thicker joints on medium sized
carbides.

5. Tri-foil products with nickel & manganese containing for brazing large
carbides as Cl-4900L.

6. Tri-foil alloys can help the internal stresses arise due to the different coefficient of expansion, which exists between the tungsten carbide and the base material.




Silver Brazing Alloys


Chemical Composition


AWS/JIS
Spec Class


Reference Data


Application




Ag


Cu


Zn


Cd


Other elements


Solidus oC


Liquidus oC




Cl-562


56


22


17


-


Sn-5


BAg-7


620


650

Low melting point



Cl-502Ni


50


20


28


-


Ni2


BAg-24


660


710

Wetting on carbide



Cl-5009


50


15.5


15.5


16


Ni3


BAg-3


630


690

Wetting on carbide



Cl-4900H


49


16


23


-


Mn7.5/Ni4.5


BAg-22


680


705

Wetting on carbide



Cl-4900L


49


27.5


20.5


-


Mn2.5/Ni0.5





670


690

Tri-foil for brazing larger carbides



Cl-2700H


27


38


20


-


Mn9.5/Ni5.5





680


850
