氣動式幫浦
Hot- 產品型號:
- AP-1000
- 原產地:
- 台灣
詳細規格及用途描述
AP-1000
Rated pressure: 700kg/cm2
Usable oil capacity: 1000c.c
Output flow rate: UNLOAD: 1.28 liter/min
LOAD: 0.16 liter/min
Air pressure range: 7-10 bar
Oil port thread: 3/8 NPT
Dimension: 260x130x200mm
Weight: 6.6kg
AP-3000
Rated pressure: 700kg/cm2
Usable oil capacity: 3000c.c
Output flow rate: UNLOAD: 1.28
LOAD: 0.16
Air pressure range: 7-10 bar
Oil port thread: 3/8 NPT
Dimension: 300x160x245mm
Weight: 10kg
