AHD 1080P 车用摄影机
- 产品型号:
- AHD 1080P Camera
- 原产地:
- 台湾
详细规格及用途描述
1/3” CMOS Sensor
Effective Pixel 1920 (H) x 1080 (V)
Progressive scan RGB CMOS
Sensitivity: 0.01 Lux (F1.2 )
Infrared Ray LED: 12 pcs
Synchronizing System: Internal Sync., 2:1 Interlace
Mirror Function
Auto Gain Control: AUTO
Backlight Compensation: AUTO
Noisy Reduction: 3D
S/N Ratio More than 52dB (AGC OFF)
Gamma Compensation 0.45
Electronic Shutter: Auto【 1/60(50)~1/110,000】
Video Output: AHD 1.0Vp-p75Ω
Lens Mount: 3.6mm megapixel lens (2.5 ━ 12mm optional)
Waterproof: IP67
Adjusting Degree: Pan +/- 180 degree ; Tilt 0-50 degree
DC: 9~18V / 80mA (LED off) / 140mA (LED on)
76.4(L) x 56 (H) x 60(W) mm / 160g
Operating Temperature: -25℃～＋70℃
