ATOMIZER PULVERIZER

▶▶ Introduction :

Dust-Free Performance
Compact Economical For Fine Grinding
Highest Capacities, Lowest Cost

▶▶ Features :


Efficiency And Compactness
Every Micron-Pulverizer has built-in economy. The compactness of every unit means savings in valuable floor space.
Quick Easy Cleaning
The distinctive design makes all parts accessible quickly and easily for inspection or cleaning.
Labor Savings
As with any machine some degree of intelligent supervision is needed, but the operation of the Micron Pulverizer can be entrusted to unskilled workers for long periods of time without concern for its well being.
Unvarying Production
When a Micron Pulverizer is set to deliver a product it does so hour after hour, with a minimum of attention and an unvarying product. It is commonplace for the Pulverizer to operate 24 hours a day, day after day, and the products is the same form start to stop.

Guaranteed Performance
Every Micron Pulverizer is guaranteed to do the job for which it is sold. The She Hui Testing Laboratory will test pulverize materials and furnish exact data and information and every pulverizer will perform exactly the same way in commercial production.
▶▶ Flow-Sheet :
‧Micron Pulverier With Pulsaire Collector



Pictured above is a system where a Pulsaire is Venting and collecting ground material from a Micron Pulverizer. Whit its high filtering efficiency Pulsaire Collector offers a constant operating Pressure in the system, assuring a stable and continuous run of the Micron Pulverizer at its maximum capacity.
‧Micron Pulverier With Micron Seprator And Pulsaire Collector

By incorporating a Micron Separator, most reliable air classifier, Micron Pulverizer can be operated with greater capacity with uniform product fineness. The rejected oversize particles may either be returned to the Micron Pulverizer for another pass or be thrown out of the circuit. Accepted fines only are collected in a Micron Pulsaire. Thus, Excessive grinding in the Pulverizer can be eliminated which results in a substantial capacity increase and less wear-rate of Micron Pulverizer.
▶▶ Application And Capability :


MaterialModelCapacity(kg/hr)
Product(mesh)

Active Carbon
AP-2DH
220
250mesh pass 95%

Almond Meal
AP-1SH
290
60mesh pass 77%
Aluminium Fluoride
AP-1SH
140
250mesh pass 94%
Animal Feed
AP-4TH
2000
almost pass 40mesh
Dried Banana
AP-B
95
100mesh pass 97%
Barley
AP-2DH
105
100mesh pass 95%
Caffeine
AP-1SH
190
40mesh pass 99%
Calcium Carbonate
AP-2DH
800
100mesh pass 99%
Calcium Hydroxide
AP-1SH
67
300mesh pass 89%
Carbon Black
AP-4TH
1000
size reduction of grit
Chalk
AP-4TH
2700
325mesh pass 99%
Coal, Anthracite
AP-2DH
350
100mesh pass 96%
CocoaAP-2DH
800
100mesh pass 93%
Starch
AP-4TH
5350
almost pass 200mesh
Fish Meal
AP-2DH
300
80mesh pass 90%
Granule Sugar
AP-2DH
190
300mesh pass 98%
Kaolin
AP-4TH
1930
200mesh pass 99%
PigmentAP-2DH
200
almost pass 300mesh
