Asymmetrical high power LED inground light
- Model:
- B2BE0616 B2BE0618
- Country of Origin:
- China
Detail Specifications / Descriptions
Housing: 12# Die-casting grey powder coated
aluminum .T=60-80µm.
Adhesion of ISO class 1/ASTM class 4B
Front ring: Stainless steel (SUS 304#, 316# optional)
Glass: Step tempered clear glass. T=8mm
Loading capacity: Exert force area of
ø10=510kgs ø30=840kgs ø60=1760kgs
Lens: Optical lens, efficiency≥85%
Cable gland: IP-68 PG-9 PVC
Gasket: Molding shaped silicone seal
LED: TO type power LED
PCB: Excellent heat conductivity aluminum,
coefficient of heat Conductivity≥2.0w /mk
Driver: Constant current output
Single color LED=1-circuit output
RGB 3in1 LED=3-circuit output
Operating temperature: -20℃~40℃
Power cable: H05RN-F 2X1.0mm² L=0.5m
(low voltage)
H05RN-F 3X0.75mm²L=0.5m
(high voltage)
H05RN-F 4X0.75mm² L=0.5m
(for RGB)
Mounting sleeve: 16#、125# option
