Specification:
01. Auto detection-the starting point is pierce or edge cutting. Get the correct preheating time and the correct piercing motion to cut.
02. Auto speed reducing-(100％-50％)when cutting circle or arc(plasma cutting), Reduce speed to get little or no bevel.
03. Two different cutting speeds-when cutting thicker plates, the beginning speed should be slower than the normal speed, in order to shorten the lead in distance.
04. The CNC pulse setting can go up to xxxx. xxxx, 8 digital numbers in total. The CNC Tolerance is 0. 5 to ten million.
05. Kerf function.
06. Pipe cutting function. (option)
07. After kerf calculation, the end point of inner circle is protuberant or concave.
08. Set radius or diameter input for kerf function.
09. Gas cutting special function-pierce all starting points first(use improper nozzle),then back to starting point to cut the shape(use proper nozzle).
10. Auto continue cutting between each plate,(CNC will automatically cut from one end of a plate to the next piercing point), to reduce piercing times.
11. Auto nesting for circles.
12. Automatically divide circles to 2 or 3 pieces when too big to cut.
13. Rort and cone development in CNC shape patterns.
14. When cutting, can stop and move to anywhere to re-cut.
15. Wireless remote control function-acc/ dec speed, stop, go on , forward, reverse, cut.
16. Automatically acceleration/deceleration at corners.
17. Automatically adjust graphic angles to fit plate position.
18. I/O defined by user, if I/O relay breakdown-connect to another connection and redefine.
19. Piercing motion can be defined by user.
20. Include gas/plasma cutting condition, according to plate thickness. (adjustable)
21. Set kerf with CAM code table.
22. Shape patterns are expandable.
23. One or multi torch cutting square plate patterns(for gas cutting, and for plasma cutting).
24. Many shape patterns for steel construction.
25. Nesting on CNC.
26. HPGL files converting function, it automatically nests cutting path-inside Shape cutting first, than outside shape cutting last.
27. Tracing function and data saving in CNC.
28. Can easily and rapidly edit shape on CNC (by line arc concept, not by G, M code).
29. Can convert end-plate-cover circle data to ellipse data for CNC cutting.
30. Reverse acc/dec function(different with corner acc/dec),to extend machine life.
31. File can be selected by date or by name. |
|
