LED type Ping-ellipsoid

LED Qty: 48PCS

Demension: 500×19×17mm

Module interface Yellow Red Green Blue4×0.5mm2×60mm RV Traverse

Interface definition yellow anode, red, green and blue cathode

Cluster Qty: 3m(6pcs)

Module space between: 60mm±5％

Weight: 150g±5％

Lifespan: MTBF＞50000hours

enviroment parameter

working temperature —20℃~ 50℃

Defend Grade: IP65 Fully meet the Outdoor lamps protection standards

Electronic specification

Working input voltage DC5V±5%

Max power 3.6W

Driving mode Invariablenes Voltage! (Insure every LED working under the invariablenes voltage)

lighting capability

Luminous Flux: Red:72lm Green:115.6Im Blue:58Im

Beam angle >120°
