Certifications: UL E155159

Rating : 0.5 — 5.0Amp . Input Power :125Vac 12Vdc . Interrupting Capacity : 200Amp× 125Vac . Dielectric

Strength : 1,500Vac 1 minute. Insulation Resistance: >500 Meagaohms .Voltage Drop : Less than 0.25v.

Reset Time : 200% of rating current within 50 seconds .150% of rating current within 5 seconds .

Contact Endurance : 125Vac × 150 % of rated current >500 Cycles.

Reset : Manual Push Reset/Auto Reset.

Calibration (at 25℃)

0.5Amp-1.3Amp

100%of rated current :hold,No-Trip

150%of rated current :Trip in one Hour

200%of rated current :Within 40 seconds

300% of rated current :Within 4.0 seconds

1.4Amp-5.0Amp

100%of rated current :hold,No-Trip

150%of rated current :Trip in one Hour

200%of rated current : Within 45seconds

300% of rated current : Within 4..5 seconds
