Self-centering device

Slide with step function

Turntable with scale

Tool box under the pole

Aluminum cylinder body

Vertical and horizontal arms with pneumatic dual locking device

Pole is tiltable

Tubeless Inflating device

Complete with air reserve tank

Side inflating control pedal

Manometer for inflating pressure control equipped with deflating push button

Optional Helper-R

Technical Data

Rim clamping Outside: 11＂-20＂

Rim clamping Inside: 13＂-24＂

Wheel Width: 13＂

Max.Tire Diameter: 1150mm(44＂)

Operating Pressure: 10bar 145psi

Turntable Height: 780mm

Power Supply: 110/220/380V-3ph

Motor Power: 1 .1/1.1/0.75kw

Net Weight: 295kg
