Electro-Permanent Magnetic Index Table

Electro-Permanent Magnetic Index Table

Model:
EEPM-IT
Country of Origin:
Taiwan

Detail Specifications / Descriptions

Suitable for horizontal milling & boring machine on precision machining of division.
1. We changed traditional clamping way of Index Table. Made with Electro-Permanent Magnetic Chuck, can do 5 side machining, without any obstructed movement of cutters during machining.
2. Super magnetic force 1000kgf/100cm2. (4 Poles)
3. Structure of Electro-Permanent Magnetic Chuck, 3~10 seconds control for power ON & OFF. No electric power supply required to keep the chuck ON. So no electric cable disturbed, can be turning freely.
4. Magnetic power adjustable.
5. Pneumatic system to rotate and fix the table, Easy and convenient to operate.
6. Heavy Duty construction, built of FC35 cast iron. Suitable for heavy duty machining.
