Crankshaft Grinding Machine

Crankshaft Grinding Machine

Model:

RUARO RG270

Country of Origin:

Italy

Minimum Order:

1pc

Delivery Lead Time:

prompt

Delivery FOB Port:

Taiwan

Payment Condition:

T/T 30% in advance, balance of 70% before shipment

Detail Specifications / Descriptions
Specifications

Capacity centre height over table 270mm. (10 5/8”)
Swing over table 540mm. (21 1/4”)
Max. centre distance 1750mm. (68 57/64”)
Max. chuck distance 1700mm. (66 59/64”)
Max. eccentricity of fixtures 120mm (4 23/32”)
Max. grinding diameter with new wheel. 160 mm (6 5/16”)
Swing over rests 160 mm (6 5/16”)
Diameter of chucks 200 mm (7 7/8”)
Max. weight admitted on centres 180 Kg. (397 lbs)

Grinding wheel

Max. diameter 710 mm (27 15/16)
Normal thickness 25mm (63/64)
Max. thickness 70mm (2 3/4)

Speeds

Wheelhead feed per handwheel revolution 1 mm
Wheelhead rapid traverse 140 mm
Wheelhead fine feed 170 mm
Workhead spindle speeds 24-45-70 rpm
Table fine feed per handwheel revolution 6 mm.
Automatic table feed rate 5000 mm./min (196 27/32”)

Three phase motors

Wheelhead motor 6 hp
Workhead motor 0,75 hp
Hydraulic power unit motor 2 hp
Coolant pump motor 0,30

Dimensions and weights

Overall dimensions:
Length 6300 mm. (248 1/32”)
Width 1900 mm. (74 52/32”)
Height 1520 mm. (59 13/16”)
Net weight, approx. 4250 kg. (8710 lbs)
Seaworthy box:
Length 4500 mm. (177 3/16”)
Width 1920 mm. (75 19/32”)
Height 1900 mm. (74 13/16”)
Gross weight, approx. 4950 kg. (10915 lbs)

Specifications & features are subject to modifications.

Good condition
Have to re-paint repairs
Used
