Garage Door Remote Products - Remote Control Devices ( For Garage Door And Car Alarms), Remote Contr
- Model:
- SRC019E
- Country of Origin:
- Taiwan
Detail Specifications / Descriptions
Two-channel TX RF transmitter:
Frequency: 315MHz / 433.92MHz (Option)
CODE Type: 1.)Compatible with either fixed code or 2.)rolling code transmitters (Option)
Two form-C dry relay contact (NO/NC/common) outputs
Operating frequency: 315MHz / 433.92MHz (Option)
Operating voltage: 11VDC to 24VDC (Option)
Operating distance: up to 650 feet (open air)
Operating temperature: -20 to 72 degrees Celsius (-4 to 162 degrees Fahrenheit)
Current drain: 8mA at 12VDC (standby), 45mA per channel at 12VDC (activated)
Sensitivity: -87dBm (typical)
Data format: PWM
RF codes: 18 quintillion (SK-917T2A), 68 billion (SK-919TD2A)
RF channels: 2
Number of stored transmitter codes: 15 per channel, 30 per receiver
Receiver outputs: two form C dry relay contacts (NO/NC/common); 10A at 24VDC
Receiver output modes: programmable 4-second momentary (default), 1-second momentary, toggle or latch
