* Compressor: 5HP (rotary compressor)

* Measurement: H115xW53xD78cm

* Weight: 160Kgs

* Liquid storage: 12Kgs

* Voltage: 3Ø 220V 60Hz

* Appliance Freon: R-22 (special order are welcome)

* Appliance site: Freon reloading factory Bus maintenance and middle size air conditioner repair

Function

* Recycle, fill, reclaim, wash 4 in 1.

* By hand/automatic air and exhaust equipment.

* In and out entrance are assembled with 2—and 6—connector.

* Air and liquid Freon are recyclable. Recycle speed: liquid about 5Kg/min Air about 1.6kg/min

* Froen basket is attached with measurement and liquid level ball. The stock of recycle, capacity and fill can be seen clearly.

* During recycle process that impurity, vapour, oil air, acid material can be separated and exhausted. It can exhaust air automatically.

* Assembled with Freon recycle window enable to inspect the procession.

* Automatic cool equipment is assembled. It won’t damage the compressor even for long time operation.

* It is assembled with the function of close down when the basket is full, alarm, 3 minutes protection switch.

* Liquid loading to avoid uncondensed air to exhaust. It stabilizes reloading speed.

* Once the recycle process is finished, machine will stop, unload, automatically.
