ETS-2MT CNC IN-LINE AUTO ANGLED SOLDERING MACHINE

ETS-2MT CNC IN-LINE AUTO ANGLED SOLDERING MACHINE

Model:
ETS-2MT
Country of Origin:
Taiwan

Detail Specifications / Descriptions

Technical Specifications:
Soldering way: Jig up/down
Power source: AC220V 2000W
Machine dimension : 500(L) x 850 (W) x 660(H)mm
Weight / Air pressure : 75KGS/5kgs/cm2
Inner pot size :295(L) x 105 (W) x 65(H)mm
Cycle time :10-20 pcs / 10-12sec
Pot Material : Titanium
Temperature : 600℃ Max.
Suitable coil : any coil
Dip cup up/down distance: 76mm (Controlled by Cylinder)
